JD-2600A Auto Lensmeter for Optical Lab — UV Tx, ABBE Number & Progressive Verification
5.0(3 reviews)7" touch-LCD auto lensmeter with progressive recognition, UV-Tx, ABBE number and contact-lens measurement — built for the busy dispensing lab.
- SKU
- OPS-JD-2600A
- Brand
- OpticsMED
- Warehouse
- Los Angeles, US · Rotterdam, NL
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
Regulatory: This product is sold to qualified medical professionals only. It is not a substitute for clinical judgement and must be used in accordance with applicable local regulations. Manufacturer specifications, intended use, and any contraindications are described in the supplied IFU. We make no medical, diagnostic, or therapeutic claims beyond those documented by the manufacturer in the included regulatory paperwork.
Clinical overview
Product overview
The JD-2600A is the touchscreen-driven flagship of the JD auto-lensmeter line. Progressive recognition, UV transmissivity reading, ABBE compensation and contact-lens mode all in a tabletop chassis — one device covers the full verification workflow of a modern optical lab.
Key features
- 7" tilting TFT colour touch LCD — finger-driven, no dial-spinning.
- Auto recognition of single-vision, progressive and contact lenses; manual override available.
- Built-in UV transmissivity tester — check lens UV coverage in the same pass.
- ABBE number reading 30–60 for material identification.
- Automatic PD measurement, automatic progressive measurement, 0.1 s capture speed.
- Built-in thermal printer + PC data export for paperless workflows.
Technical specifications
| Sphere | 0 to ±25 D (0.01 / 0.12 / 0.25 D step) |
|---|---|
| Cylinder | 0 to ±9.99 D (0.01 / 0.12 / 0.25 D step) |
| Axis | 0° to 180° (1° step) |
| ADD | 0 to +9.99 D (0.01 / 0.12 / 0.25 D step) |
| Prism | 0 to 15Δ (0.01 / 0.12 / 0.25Δ step) |
| Cylinder mode | +, +/-, - |
| Prism mode | X-Y, P-B |
| Contact lens | Soft / hard |
| Modes | Single / progressive / auto recognition / contact lens |
| Lens diameter | Ø20 to 108 mm |
| PD range | 45 to 90 mm (0.25 mm step) |
| Speed | 0.1 s |
| ABBE | 30 to 60 |
| Display | 7" TFT LCD touch |
| Printer | Thermal |
| Dimensions / weight | 222 × 161 × 372 mm / ~5 kg |
| Power | 100–120 V / 200–110V/220V, 50/60 Hz |
Built for
Optical labs, dispensing opticals and busy refractive practices that handle progressive Rx and contact lenses daily — and want one machine doing all the verification steps without bench-juggling.
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
