SJG-800 Patternless Edger

Patternless Edger SJG-800 Features: Edging system For fast edging all kinds of material of lens Bevelling and polishing All various of edging pressure for different lenses On line function Tracing system Easy to use and maintain Combined scan and lens layout into one It will take only 0.5 second to finish the scan of lens Real-time imaging helps to confirm center of lens Automatically eliminate lens degree, prism 7 inch color touch screen with high resolution 1280×800 Synchronously connect 2 sets edging machine with one tracing machine Parameters: Edging Body Edging Mode Beveling, Flat Edging, Grooving, Safety Beveling, Polishing Clamping pressure Third gear for choice Lens Glass, PC, CR, HI, HR, TC Edging Size 22-80mm Accuracy Tolerance +/-0.01mm Power Supply AC110V/220V, 50/60HZ Power 550W(Max) Dimension 570x540x460mm Weight 49KGS Others High-resolution 640×480, true color, 5.7 inch TFT LCD, lens photograph displayed as 1:1 and with use-friendly operating interface. Tracer Dimension 240x180x130mm ADD adjustment range 6mm Weight 5KG Power Supply AC115V/230V, 50/60HZ Touch screen 7 inch capacitive screen
